solrconfig.xml, request handlers and search components are configured.A request handler processes requests coming to Solr. These might be query requests or index update requests. You will likely need several of these defined, depending on how you want Solr to handle the various requests you will make.A search component is a feature of search, such as highlighting or faceting. The search component is defined in
solrconfig.xmlseparate from the request handlers, and then registered with a request handler as needed.These are often referred to as “requestHandler” and “searchComponent”, which is how they are defined in
Every request handler is defined with a name and a class. The name of the request handler is referenced with the request to Solr, typically as a path. For example, if Solr is installed at
http://localhost:8983/solr/ and you have a collection named “gettingstarted”, you can make a request that looks like this:
This query will be processed by the request handler with the name
/select. We’ve only used the “q” parameter here, which includes our query term, a simple keyword of “solr”. If the request handler has more parameters defined, those will be used with any query we send to this request handler unless they are over-ridden by the client (or user) in the query itself.
If you have another request handler defined, you would send your request with that name. For example,
/update is a request handler that handles index updates (i.e., sending new documents to the index). By default,
/select is a request handler that handles query requests.
Request handlers can also process requests for nested paths of their names, for example, a request using
/myhandler/extrapath may be processed by a request handler registered with the name
/myhandler. If a request handler is explicitly defined by the name
/myhandler/extrapath, that would take precedence over the nested path. This assumes you are using the request handler classes included with Solr; if you create your own request handler, you should make sure it includes the ability to handle nested paths if you want to use them with your custom request handler.
It is also possible to configure defaults for request handlers with a section called
initParams. These defaults can be used when you want to have common properties that will be used by each separate handler. For example, if you intend to create several request handlers that will all request the same list of fields in the response, you can configure an
initParams section with your list of fields. For more information about
initParams, see the section InitParams in SolrConfig.
The primary request handler defined with Solr by default is the “SearchHandler”, which handles search queries. The request handler is defined, and then a list of defaults for the handler are defined with a
For example, in the default
solrconfig.xml, the first request handler defined looks like this:
<requestHandler name="/select" class="solr.SearchHandler"> <lst name="defaults"> <str name="echoParams">explicit</str> <int name="rows">10</int> </lst> </requestHandler>
This example defines the
rows parameter, which defines how many search results to return, to “10”. The
echoParams parameter defines that the parameters defined in the query should be returned when debug information is returned. Note also that the way the defaults are defined in the list varies if the parameter is a string, an integer, or another type.
All of the parameters described in the section Searching can be defined as defaults for any of the SearchHandlers.
defaults, there are other options for the SearchHandler, which are:
appends: This allows definition of parameters that are added to the user query. These might be filter queries, or other query rules that should be added to each query. There is no mechanism in Solr to allow a client to override these additions, so you should be absolutely sure you always want these parameters applied to queries.
<lst name="appends"> <str name="fq">inStock:true</str> </lst>
In this example, the filter query “inStock:true” will always be added to every query.
invariants: This allows definition of parameters that cannot be overridden by a client. The values defined in an
invariantssection will always be used regardless of the values specified by the user, by the client, in
<lst name="invariants"> <str name="facet.field">cat</str> <str name="facet.field">manu_exact</str> <str name="facet.query">price:[* TO 500]</str> <str name="facet.query">price:[500 TO *]</str> </lst>
In this example, facet fields have been defined which limits the facets that will be returned by Solr. If the client requests facets, the facets defined with a configuration like this are the only facets they will see.
The final section of a request handler definition is
components, which defines a list of search components that can be used with a request handler. They are only registered with the request handler. How to define a search component is discussed further on in the section on Search Components below. The
components element can only be used with a request handler that is a SearchHandler.
solrconfig.xml file includes many other examples of SearchHandlers that can be used or modified as needed.
The UpdateRequestHandlers are request handlers which process updates to the index.
In this guide, we’ve covered these handlers in detail in the section Uploading Data with Index Handlers.
It is possible to configure a request handler to search across shards of a cluster, used with distributed search. More information about distributed search and how to configure the shardHandler is in the section Distributed Search with Index Sharding.
Implicit Request Handlers
Solr includes many out-of-the-box request handlers that are not configured in
solrconfig.xml, and so are referred to as “implicit” – see Implicit RequestHandlers.
Search components define the logic that is used by the SearchHandler to perform queries for users.
There are several default search components that work with all SearchHandlers without any additional configuration. If no components are defined (with the exception of
last-components – see below), these are executed by default, in the following order:
|Component Name||Class Name||More Information|
||Described in the section Query Syntax and Parsing.|
||Described in the section Faceting.|
||Described in the section MoreLikeThis.|
||Described in the section Highlighting.|
||Described in the section The Stats Component.|
||Described in the section on Common Query Parameters.|
||Described in the section Collapse and Expand Results.|
If you register a new search component with one of these default names, the newly defined component will be used instead of the default.
First-Components and Last-Components
It’s possible to define some components as being used before (with
first-components) or after (with
last-components) the default components listed above.
<arr name="first-components"> <str>mycomponent</str> </arr> <arr name="last-components"> <str>spellcheck</str> </arr>
If you define
components, the default components (see above) will not be executed, and
last-components are disallowed:
<arr name="components"> <str>mycomponent</str> <str>query</str> <str>debug</str> </arr>
Other Useful Components
Many of the other useful components are described in sections of this Guide for the features they support. These are:
SpellCheckComponent, described in the section Spell Checking.
TermVectorComponent, described in the section The Term Vector Component.
QueryElevationComponent, described in the section The Query Elevation Component.
TermsComponent, described in the section The Terms Component.
RealTimeGetComponent, described in the section RealTime Get.
ClusteringComponent, described in the section Result Clustering.
SuggestComponent, described in the section Suggester.
AnalyticsComponent, described in the section Analytics.
Other components that ship with Solr include:
ResponseLogComponent, used to record which documents are returned to the user via the Solr log, described in the ResponseLogComponent javadocs.
PhrasesIdentificationComponent, used to identify & score “phrases” found in the input string, based on shingles in indexed fields, described in the PhrasesIdentificationComponent javadocs.
